For Sale: Complete 10 MW / 2 MW Cogeneration Power Plant
Available for immediate acquisition: a fully integrated power plant for the combined and efficient production of heat
and electricity through a cogeneration system
Technical Description
The whole installation (Model: E.V.A.) for sale includes components listed below
STEAM BOILER
Manufacturer
Wehrle Werk
Year
1999
Heating capacity
up to 10 MW
Fuel type
biomass/RDF
Fuel gas volume
20.000 Nm³/h
Fuel consumption
approx. 2500 kg/h
Fuel need
approx. 20 000 t/a
Average combustion temperature
approx. 900°C
Main steam pressure
water steam with 40 bar
Main steam temperature
410°C
Main steam mass flow
11 t/h
Combustion power gross
max. 10.000 kW
Combustion power gross
min. 7000 kW
Water content
25 m³
STEAM TURBINE
Manufacturer
KKK / Siemens SST110
Electrical capacity
up to 2 MW
Year
1999
serial number 4.746.114
Type
TWIN steam turbine used as condensation machine AFA4 / AFA6 GTA electrohydr
Turbine control
(Kuhse with Siemens S5)
AFA 4: drive speed: 1500 1/min
rapidlocking
Speed min
1678 1/min
Speed max
1712 1/min
Gear ratio
11.96:1
Live steam pressure
min. 31 bar – max. 47 bar
Live steam temperature
min. 350°C – max. 428°C
Waste steam pressure
min. 0.50 bar – max. 2.50 bar
in operation 1.50 bar
Waste steam temperature
347°C
AFA 6: drive speed 1500 1/min
AND ALL OTHER COMPONENTS NECESSARY TO BUILD THE COMPLETE POWER PLANT!
Such as
Sterling water feed pumps
Boiler water system from Hager & Elsässer with softening installation and reverse osmosis unit
Horizontal superheater
Economizers
Reduction station
Cooling station
Water treatment plant
Fuel feeding system
Air protection devices with bag filters
Chimney 33 m high – located inside the boiler room (above the roof of 17 m)
which discharges exhaust gases and auxiliary facilities
mainly connected with fuel storage
And many others
Ready to build in a new location NOW!
Available now!
The installation was built in Germany
where it worked on RDF fuel
Then
sold and transported to Poland (current location)
